Detailed Description

Creation and investigation of an NCFS generic detector structure.

Copyright(c) 2021 NCFS/IIHE, All Rights Reserved.                           *
                                                                            *
Authors: The Netherlands Center for Fundamental Studies (NCFS).             *
         The Inter-university Institute for High Energies (IIHE).           *
                   Website : http://www.iihe.ac.be                          *
           Contact : Nick van Eijndhoven (nickve.nl@gmail.com)              *
                                                                            *
Contributors are mentioned in the code where appropriate.                   *
                                                                            *
No part of this software may be used, copied, modified or distributed       *
by any means nor transmitted or translated into machine language for        *
commercial purposes without written permission by the IIHE representative.  *
Permission to use the software strictly for non-commercial purposes         *
is hereby granted without fee, provided that the above copyright notice     *
appears in all copies and that both the copyright notice and this           *
permission notice appear in the supporting documentation.                   *
This software is provided "as is" without express or implied warranty.      *
The authors make no claims that this software is free of error, or is       *
consistent with any particular standard of merchantability, or that it      *
will meet your requirements for any particular application, other than      *
indicated in the corresponding documentation.                               *
This software should not be relied on for solving a problem whose           *
incorrect solution could result in injury to a person or loss of property.  *
If you do use this software in such a manner, it is at your own risk.       *
The authors disclaim all liability for direct or consequential damage       *
resulting from your use of this software.                                   *

// Class NcDetector
// Creation and investigation of an NCFS generic detector structure.
//
// This class provides a facility to build up a hierarchical structure
// to store detector signals.
// Detector signals are represented by NcSignal objects that belong to
// NcDevice objects. An Ncsignal object that is related to an NcDevice
// is called a "hit" and can be stored in the NcDevice via the
// generic AddHit memberfunction.
// A group of NcDevice objects may be combined in an NcDetectorUnit object
// to represent a certain sub-detector system, and several NcDetectorUnit
// objects may finally be combined into an NcDetector object to represent
// the complete experimental setup.
// Combination of these various detector elements is performed by the
// generic AddDevice memberfunction.
//
// Since the goal of recording experimental data is to investigate
// certain (astro)physical phenomena, the occurrence of a sudden
// observation of signals in the detector is called an event.
// To store the event data in an organized way, the class NcEvent is provided,
// in which the various detector structures and their recorded signals
// can be stored as indicated below.
//
// It is good practice to combine the complete detector structure in
// a single NcDetector object and then store the whole detector structure
// in an NcEvent structure by a single SetDetector invokation.
// The recorded signals may already be included in the detector structure
// at invokation of SetDetector, but depending on the format c.q. organisation
// of the (raw) detector data, it may sometimes also be practical to
// first store the detector structure without signals, then retrieve
// a pointer to the stored detector structure via invokation of GetDetector
// and finally use this pointer to navigate through the detector structure
// and store the various recorded signals.
// The use of such a single NcDetector object will in general provide the
// most efficient way to retrieve and analyze the recorded data.
// However, it is also possible to use multiple AddDevice invokations of NcEvent
// to store every NcDevice individually if the user wants to do so.
// In this case, a default NcDetector object will be created automatically
// inside the NcEvent to hold all the added devices.
// This automatically created NcDetector object may be accessed in the usual way
// via the GetDetector invokation of NcEvent.
//
// To provide maximal flexibility to the user, two modes can be used for the storage
// of devices which can be selected by means of the memberfunction SetDevCopy().
//
// a) SetDevCopy(0).
//    Only the pointers of the 'added' devices are stored.
//    This mode is typically used by making studies based on a fixed set
//    of devices which stays under user control or is kept on an external
//    file/tree.
//    In this way the NcDetector just represents a 'logical structure' for the
//    analysis of the various detector components and the recorded signals.
//
//    Note :
//    Modifications made to the original devices also affect the device
//    objects which are stored in the NcDetector structure.
//
// b) SetDevCopy(1) (which is the default).
//    Of every 'added' device a private copy will be made of which the pointer
//    will be stored.
//    In this way the NcDetector represents an entity on its own and modifications
//    made to the original devices do not affect the NcDevice (or derived) objects
//    which are stored in the NcDetector.
//    This mode will allow 'adding' many different devices into an NcDetector by
//    creating only one device instance in the main programme and using the
//    Reset() and parameter setting memberfunctions of the object representing the device.
//
//    Note :
//    The copy is made using the Clone() memberfunction.
//    All devices (i.e. classes derived from TObject) have the default TObject::Clone()
//    memberfunction.
//    However, devices generally contain an internal (signal) data structure
//    which may include pointers to other objects. Therefore it is recommended to provide
//    for all devices a specific copy constructor and override the default Clone()
//    memberfunction using this copy constructor.
//    Examples for this may be seen from NcCalorimeter, NcSignal and NcDevice.
//
// See also the documentation provided for the memberfunction SetOwner().
//
// In order to tailor the performance of the various detector elements
// with specific (sub)detector characteristics, the user may extend the
// functionality of the standard classes mentioned above, by introducing
// new classes which are derived from the standard ones.
// See the examples below to illustrate this.
//
// In addition to the detector structures and their recorded signals,
// the NcEevent class also provides facilities to store reconstructed
// objects like tracks (NcTrack), jets (NcJet) and vertices (NcVertex)
// together with timing information (NcTimestamp).
//
// Navigation through the detector structures to obtain the contained data
// may be performed via the various memberfunctions of the classes
// NcDetector, NcDetectorUnit, NcDevice, NcSignal and also NcEvent.
//
// Examples :
// ==========
//
// The IceCube Neutrino Observatory at the South Pole :
// ----------------------------------------------------
// The IceCube detector consists of more than 5000 Digital Optical Modules (DOMs)
// that are buried deep in the Antarctic ice in a hexagonal grid.
// At the deepest central part of the detector, additional DOMs have been added
// to form a denser core dubbed DeepCore.
// In addition to this, there are also DOMs located at the ice surface called IceTop.
// For the storage and analysis of the IceCube data, the following hierarchical
// detector structure could be envisaged :
// * Every DOM is represented via an NcDevice.
// * The IceTop DOMs are grouped into an NcDetectorUnit object named "IceTop".
// * All DOMs that are buried under the surface are grouped into an
//   NcDetectorUnit object named "InIce".
// * The DeepCore DOMs are grouped into an NcDetectorUnit object named "DeepCore".
//   Note here that DeepCore DOMs also belong to the InIce part, but this can
//   be handled by the introduction of new classes derived from NcDevice,
//   like for instance IceIDOM (derived from NcDevice) to represent a generic
//   InIce DOM, IceDCDOM (derived from IceIDOM) to represent a DeepCore DOM
//   and IceICDOM (derived from IceIDOM) to represent an InIce DOM not belonging to DeepCore.
// * Finally the IceTop, InIce and DeepCore detector units are grouped
//   into the overall NcDetector named "IceCube".
//
// The IceCube data analysis framework is available in the directory "icepack".
// Note that in this framework also a new class IceEvent (derived from NcEvent)
// has been introduced to provide specific IceCube related functionality.
//
// The Radio Neutrino Observatory in Greenland (RNO-G) :
// -----------------------------------------------------
// The RNO-G detector array is foreseen to consist of 35 so called detector stations,
// each of which consists of 3 vertical strings deep in the ice equipped with antennas.
// These antennas come in two varieties, namely horizontally polarized (HPOL)
// and vertically polarized (VPOL).
// In addition to this, there are also LogPeriodic Dipole Antennas (LPDAs)
// located in 3 trenches at the surface.
// For the storage and analysis of the RNO-G data, the following hierarchical
// detector structure could be envisaged :
// * Every antenna is represented via an NcDevice.
//   To distinguish the different antenna types, new classes (derived from NcDevice)
//   are introduced, namely RnoHPOL, RnoVPOL and RnoLPDA.
// * To represent the various strings, a new class RnoString (derived from NcDetectorUnit)
//   is introduced.
// * To represent the various trenches, a new class RnoTrench (derived from NcDetectorUnit)
//   could be introduced.
//   Although a trench is not an electronically connected entity like a string, and the LPDAs
//   are foreseen to perform as individual devices, this structure may have some benefits
//   in the data analysis phase.
// * All RnoHPOL and RnoVPOL objects are grouped in the corresponding RnoString objects.
// * The RnoLPDA objects are grouped in the corresponding RnoTrench objects.
// * The 3 RnoString objects and the 3 RnoTrench objects are grouped in a RnoStation object
//   that is derived from NcDetectorUnit.
// * Finally all 35 RnoStation objects are grouped into the overall NcDetector named "RNO".
//
// The RNO-G data analysis framework is available in the directory "rnopack".
// Note that in this framework also new classes RnoDetector (derived from NcDetector) and
// RnoEvent (derived from NcEvent) have been introduced to provide specific RNO-G related functionality.
//
//--- Author: Nick van Eijndhoven, IIHE-VUB, Brussel, June 25, 2021  07:39Z
//- Modified: Nick van Eijndhoven, IIHE-VUB, Brussel, June 27, 2021  09:59Z

Definition at line 11 of file NcDetector.h.

Public Member Functions
	NcDetector (const char name="", const char title="")

	NcDetector (const NcDetector &q)

virtual	~NcDetector ()

virtual TObject *	Clone (const char *name="") const

Public Member Functions inherited from NcDetectorUnit
	NcDetectorUnit (const char name="", const char title="")

	NcDetectorUnit (const NcDetectorUnit &q)

virtual	~NcDetectorUnit ()

void	AddDevice (NcDevice &d)

void	AddDevice (NcDevice *d)

virtual void	Data (TString f="car", TString u="rad")

virtual void	Data (TString f="car", TString u="rad") const

void	DisplayHits (TString classname, Bool_t follow, Bool_t inc, Int_t idx=1, Float_t scale=-1, Int_t dp=0, Int_t mode=1, Int_t mcol=4)

void	DisplayHits (TString classname, Bool_t follow, Bool_t inc, TString name, Float_t scale=-1, Int_t dp=0, Int_t mode=1, Int_t mcol=4)

NcDetectorUnit *	GetDetectorUnit (TString name, Bool_t follow)

Int_t	GetDevCopy () const

NcDevice *	GetDevice (Int_t i) const

NcDevice *	GetDevice (TString name, Bool_t follow)

TObjArray *	GetDevices (TString classname, Bool_t follow, TObjArray *devices=0)

TObjArray *	GetHitsDevices (TString classname, Bool_t follow, Bool_t inc, TObjArray *hits=0, TString name="none", Int_t mode=0, Int_t opt=0)

NcDetectorUnit *	GetIdDetectorUnit (Int_t id, Bool_t follow, TObjArray *devs=0)

NcDetectorUnit *	GetIdDetectorUnit (Int_t id, TString classname, Bool_t follow)

NcDevice *	GetIdDevice (Int_t id, Bool_t follow, TObjArray *devs=0)

NcDevice *	GetIdDevice (Int_t id, TString classname, Bool_t follow)

NcSignal *	GetIdHit (Int_t id, TString classname, Bool_t follow, Bool_t inc)

Int_t	GetNdevices (Bool_t follow)

Int_t	GetNdevices (TString classname, Bool_t follow, TObjArray *hits=0)

Int_t	GetNhitsDevices (TString classname, Bool_t follow, Bool_t inc)

void	RemoveDevice (NcDevice *d)

virtual void	Reset (Int_t mode=0)

void	SetDevCopy (Int_t j)

virtual void	SetOwner (Bool_t own=kTRUE)

void	ShowDevices (Int_t mode=1, Bool_t header=kTRUE)

void	ShowDevices (TString classname, Int_t mode=1, Bool_t header=kTRUE)

void	ShowHits (TString classname, Bool_t follow, Bool_t inc, Int_t mode=1, TString f="car", TString u="rad")

TObjArray *	SortDevices (TObjArray hits, Int_t idx=1, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

TObjArray *	SortDevices (TObjArray hits, TString name, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

TObjArray *	SortDevices (TString classname, Bool_t follow, Bool_t inc, Int_t idx=1, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray *ordered=0)

TObjArray *	SortDevices (TString classname, Bool_t follow, Bool_t inc, TString name, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray *ordered=0)

TObjArray *	SortHits (Int_t idx=1, Int_t mode=-1, TObjArray hits=0, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

TObjArray *	SortHits (TString classname, Bool_t follow, Bool_t inc, Int_t idx=1, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray *ordered=0)

TObjArray *	SortHits (TString classname, Bool_t follow, Bool_t inc, TString name, Int_t mode=-1, Int_t mcal=1, Int_t deadcheck=1, TObjArray *ordered=0)

TObjArray *	SortHits (TString name, Int_t mode=-1, TObjArray hits=0, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

Public Member Functions inherited from NcDevice
	NcDevice (const char name="", const char title="")

	NcDevice (const NcDevice &dev)

virtual	~NcDevice ()

void	AddHit (NcSignal &s)

void	AddHit (NcSignal *s)

void	DisplayHits (Int_t idx=1, Float_t scale=-1, TObjArray *hits=0, Int_t dp=0, Int_t mode=1, Int_t mcol=4)

void	DisplayHits (TString name, Float_t scale=-1, TObjArray *hits=0, Int_t dp=0, Int_t mode=1, Int_t mcol=4)

NcPosition	GetCOG (TObjArray *hits, Int_t pos=0, TString slotname="none", Int_t mode=0) const

Double_t	GetCVAL (TObjArray *hits, TString obsname, TString weightname="none", Int_t mode=0, Int_t type=1) const

void	GetExtremes (Float_t &vmin, Float_t &vmax, Int_t idx=1, TObjArray *hits=0, Int_t mode=1, Int_t deadcheck=1) const

void	GetExtremes (Float_t &vmin, Float_t &vmax, TString name, TObjArray *hits=0, Int_t mode=1, Int_t deadcheck=1) const

NcSignal *	GetHit (Int_t j) const

NcSignal *	GetHit (TString name, Int_t mode=0, Int_t opt=0) const

Int_t	GetHitCopy () const

Nc3Vector	GetHitPath (TObjArray *hits, Int_t pos=0) const

TObjArray *	GetHits ()

void	GetHits (TObjArray &selected, TString name, Int_t mode=0, Int_t opt=0, TObjArray *hits=0) const

NcSignal *	GetIdHit (Int_t id) const

Int_t	GetNhits () const

Int_t	GetNhits (TString name, Int_t mode=0, Int_t opt=0) const

Int_t	GetStatus () const

void	RemoveHit (NcSignal &s)

void	RemoveHit (NcSignal *s)

void	RemoveHits ()

void	SetHitCopy (Int_t j)

void	SetStatus (Int_t word)

void	ShowHit (Int_t j=0, TString f="car", TString u="rad") const

Double_t	SlideWindow (TObjArray hits, Double_t thres, Double_t swin, TString sname, Int_t smode=0, TString wname="none", Int_t wmode=0, Int_t i1=0, Int_t *i2=0) const

TObjArray *	SortHits (Int_t idx=1, Int_t mode=-1, TObjArray hits=0, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

TObjArray *	SortHits (TString name, Int_t mode=-1, TObjArray hits=0, Int_t mcal=1, Int_t deadcheck=1, TObjArray ordered=0)

Double_t	SumSignals (Int_t idx, Int_t mode=1, TObjArray *hits=0)

Double_t	SumSignals (TString name, Int_t mode=1, TObjArray *hits=0)

Public Member Functions inherited from NcSignal
	NcSignal (const char name="", const char title="")

	NcSignal (const NcSignal &s)

virtual	~NcSignal ()

void	AddLink (TObject *obj, Int_t j=1)

void	AddLink (TObject *obj, TString name)

virtual void	AddSignal (Double_t sig, Int_t j=1)

virtual void	AddSignal (Double_t sig, TString name)

void	AddTrack (NcTrack &t, Int_t mode=1)

void	DeleteSample (Int_t j=1)

void	DeleteSample (TString name)

virtual void	DeleteSignals (Int_t mode=0)

void	DeleteWaveform (Int_t j=1)

void	DeleteWaveform (TString name)

NcSample *	DisplaySample (Int_t j=1, Int_t i=1) const

NcSample *	DisplaySample (TString name, Int_t i=1) const

NcDevice *	GetDevice () const

Int_t	GetErrorFlag (Int_t j=1) const

Int_t	GetErrorFlag (TString name) const

NcTrack *	GetIdTrack (Int_t id) const

Int_t	GetIndices (TObject *obj, Int_t j, TArrayI &ks) const

Int_t	GetIndices (TObject *obj, TArrayI &js, Int_t k) const

Int_t	GetIndices (TObject *obj, TArrayI &js, TArrayI &ks) const

Int_t	GetIndices (TObject *obj, TString name, TArrayI &ks) const

TObject *	GetLink (Int_t j=1, Int_t k=1) const

TObject *	GetLink (TString name, Int_t k=1) const

Int_t	GetNerrors () const

Int_t	GetNlinks (TObject *obj, TString name) const

Int_t	GetNlinks (TObject *obj=0, Int_t j=0) const

Int_t	GetNsamples () const

virtual Int_t	GetNslots () const

Int_t	GetNtracks (NcTrack *t=0) const

Int_t	GetNvalues () const

Int_t	GetNwaveforms () const

NcSample *	GetSample (Int_t j=1) const

NcSample *	GetSample (TString name) const

Int_t	GetSampleIndex (TString name) const

virtual Float_t	GetSignal (Int_t j=1, Int_t mode=0) const

virtual Float_t	GetSignal (TString name, Int_t mode=0) const

virtual Float_t	GetSignalError (Int_t j=1) const

virtual Float_t	GetSignalError (TString name) const

Int_t	GetSignalFlag (Int_t j=1) const

Int_t	GetSignalFlag (TString name) const

Int_t	GetSwapMode () const

NcTrack *	GetTrack (Int_t j) const

TH1F *	GetWaveform (Int_t j=1) const

TH1F *	GetWaveform (TString name) const

Int_t	GetWaveformIndex (TString name) const

virtual void	List (Int_t j=0) const

virtual void	List (TString name) const

void	ListSample (Int_t j=0) const

void	ListTrack (Int_t j=0) const

void	ListWaveform (Int_t j=0) const

void	RemoveTrack (NcTrack &t, Int_t mode=1)

void	RemoveTracks (Int_t mode=1)

void	ResetLink (Int_t j=1, Int_t k=1)

void	ResetLink (TString name, Int_t k=1)

void	ResetLinks (TObject *obj, Int_t j=0, Int_t k=0)

void	ResetLinks (TObject *obj, TString name, Int_t k=0)

void	ResetSample (Int_t j=1)

void	ResetSample (TString name)

virtual void	ResetSignals (Int_t mode=0)

void	ResetWaveform (Int_t j=1)

void	ResetWaveform (TString name)

void	SetDevice (NcDevice *dev)

void	SetLink (TObject *obj, Int_t j=1, Int_t k=1)

void	SetLink (TObject *obj, TString name, Int_t k=1)

void	SetSample (NcSample *sample, Int_t j=1)

virtual void	SetSignal (Double_t sig, Int_t j=1)

virtual void	SetSignal (Double_t sig, TString name)

virtual void	SetSignalError (Double_t dsig, Int_t j=1)

virtual void	SetSignalError (Double_t dsig, TString name)

void	SetSwapMode (Int_t swap=1)

void	SetWaveform (TH1F *waveform, Int_t j=1)

Public Member Functions inherited from NcPosition
	NcPosition ()

	NcPosition (const NcPosition &p)

virtual	~NcPosition ()

Double_t	GetDistance (NcPosition &p, Float_t scale=-1)

Double_t	GetDistance (NcPosition *p, Float_t scale=-1)

NcPosition &	GetPosition ()

void	GetPosition (Double_t *r, TString f, TString u="rad", Float_t s=-1) const

void	GetPosition (Float_t *r, TString f, TString u="rad", Float_t s=-1) const

void	GetPositionErrors (Double_t *e, TString f, TString u="rad", Float_t s=-1) const

void	GetPositionErrors (Float_t *e, TString f, TString u="rad", Float_t s=-1) const

NcTimestamp *	GetTimestamp ()

Float_t	GetUnitScale () const

void	RemoveTimestamp ()

void	ResetPosition ()

void	SetPosition (Double_t *r, TString f, TString u="rad")

void	SetPosition (Double_t r1, Double_t r2, Double_t r3, TString f, TString u="rad")

void	SetPosition (Float_t *r, TString f, TString u="rad")

void	SetPosition (Nc3Vector &r)

void	SetPositionErrors (Double_t *e, TString f, TString u="rad")

void	SetPositionErrors (Double_t e1, Double_t e2, Double_t e3, TString f, TString u="rad")

void	SetPositionErrors (Float_t *e, TString f, TString u="rad")

void	SetTimestamp (NcTimestamp &t)

void	SetUnitScale (Float_t s)

Public Member Functions inherited from Nc3Vector
	Nc3Vector ()

	Nc3Vector (const Nc3Vector &v)

virtual	~Nc3Vector ()

Double_t	ConvertAngle (Double_t a, TString in, TString out) const

Nc3Vector	Cross (Nc3Vector &q) const

Double_t	Dot (Nc3Vector &q)

void	GetErrors (Double_t *e, TString f, TString u="rad") const

void	GetErrors (Float_t *e, TString f, TString u="rad") const

Double_t	GetNorm ()

virtual Double_t	GetOpeningAngle (Nc3Vector &q, TString u="rad")

Nc3Vector	GetPrimed (TRotMatrix *m) const

Double_t	GetPseudoRapidity ()

Double_t	GetResultError () const

Nc3Vector	GetUnprimed (TRotMatrix *m) const

Nc3Vector	GetVecLong () const

void	GetVector (Double_t *v, TString f, TString u="rad") const

void	GetVector (Float_t *v, TString f, TString u="rad") const

Nc3Vector	GetVecTrans () const

Double_t	GetX (Int_t i, TString f, TString u="rad")

Int_t	HasErrors () const

Int_t	HasVector () const

virtual void	Load (Nc3Vector &q)

Nc3Vector	operator* (Double_t s) const

Nc3Vector &	operator*= (Double_t s)

Nc3Vector	operator+ (Nc3Vector &q) const

Nc3Vector &	operator+= (Nc3Vector &q)

Nc3Vector	operator- (Nc3Vector &q) const

Nc3Vector &	operator-= (Nc3Vector &q)

Nc3Vector	operator/ (Double_t s) const

Nc3Vector &	operator/= (Double_t s)

Nc3Vector &	operator= (const Nc3Vector &q)

void	PrintAngle (Double_t a, TString in, TString out, Int_t ndig=1, Bool_t align=kFALSE) const

void	SetErrors (Double_t *e, TString f, TString u="rad")

void	SetErrors (Double_t e1, Double_t e2, Double_t e3, TString f, TString u="rad")

void	SetErrors (Float_t *e, TString f, TString u="rad")

void	SetVector (Double_t *v, TString f, TString u="rad")

void	SetVector (Double_t v1, Double_t v2, Double_t v3, TString f, TString u="rad")

void	SetVector (Float_t *v, TString f, TString u="rad")

virtual void	SetZero ()

Public Member Functions inherited from NcAttrib
	NcAttrib ()

	NcAttrib (const NcAttrib &a)

virtual	~NcAttrib ()

void	AddNamedSlot (TString s)

void	DecreaseEdgeValue (Int_t j=1)

void	DecreaseEdgeValue (TString name)

void	DeleteCalibrations (Int_t mode=0)

TF1 *	GetCalFunction (Int_t j=1) const

TF1 *	GetCalFunction (TString name) const

Int_t	GetCalWord (Int_t j=1) const

Int_t	GetCalWord (TString name) const

Int_t	GetDeadValue (Int_t j=1) const

Int_t	GetDeadValue (TString name) const

TF1 *	GetDecalFunction (Int_t j=1) const

TF1 *	GetDecalFunction (TString name) const

Int_t	GetEdgeValue (Int_t j=1) const

Int_t	GetEdgeValue (TString name) const

Float_t	GetGain (Int_t j=1) const

Float_t	GetGain (TString name) const

Int_t	GetGainFlag (Int_t j=1) const

Int_t	GetGainFlag (TString name) const

Int_t	GetLockValue (Int_t j=1) const

Int_t	GetLockValue (TString name) const

Int_t	GetNcalflags () const

Int_t	GetNcalfuncs () const

Int_t	GetNdecalfuncs () const

Int_t	GetNgains () const

Int_t	GetNnames () const

Int_t	GetNoffsets () const

Float_t	GetOffset (Int_t j=1) const

Float_t	GetOffset (TString name) const

Int_t	GetOffsetFlag (Int_t j=1) const

Int_t	GetOffsetFlag (TString name) const

Int_t	GetSlotIndex (TString name, Int_t opt=0) const

TString	GetSlotName (Int_t j=1) const

void	IncreaseEdgeValue (Int_t j=1)

void	IncreaseEdgeValue (TString name)

virtual void	Load (NcAttrib &a, Int_t j=0)

virtual void	Load (NcAttrib &a, TString name)

void	Lock (Int_t j=1)

void	Lock (TString name)

void	ResetGain (Int_t j=1)

void	ResetGain (TString name)

void	ResetOffset (Int_t j=1)

void	ResetOffset (TString name)

void	SetAlive (Int_t j=1)

void	SetAlive (TString name)

void	SetCalFunction (TF1 *f, Int_t j=1)

void	SetCalFunction (TF1 *f, TString name)

void	SetDead (Int_t j=1)

void	SetDead (TString name)

void	SetDecalFunction (TF1 *f, Int_t j=1)

void	SetDecalFunction (TF1 *f, TString name)

void	SetEdgeOff (Int_t j=1)

void	SetEdgeOff (TString name)

void	SetEdgeOn (Int_t j=1)

void	SetEdgeOn (TString name)

void	SetEdgeValue (Int_t val, Int_t j=1)

void	SetEdgeValue (Int_t val, TString name)

void	SetGain (Double_t gain, Int_t j=1)

void	SetGain (Double_t gain, TString name)

void	SetOffset (Double_t off, Int_t j=1)

void	SetOffset (Double_t off, TString name)

void	SetSlotName (TString s, Int_t j=1)

void	Unlock (Int_t j=1)

void	Unlock (TString name)

Additional Inherited Members
Public Attributes inherited from NcSignal
Bool_t	fDevset

Protected Member Functions inherited from NcDetectorUnit
void	LoadDevices (TString classname, Bool_t follow, TObjArray hits=0, NcDetectorUnit unit=0)

void	LoadHits (TString classname, Bool_t follow, Bool_t inc, TObjArray hits=0, NcDetectorUnit unit=0)

void	ShowDevicesTree (TString classname, Int_t mode=1, NcDetectorUnit *unit=0)

Protected Member Functions inherited from NcSignal
void	SetSigFlags (Int_t is, Int_t ie, Int_t j)

Protected Member Functions inherited from NcAttrib
void	SetCalFlags (Int_t gf, Int_t of, Int_t j)

Protected Attributes inherited from NcDetectorUnit
Int_t	fDevCopy

TObjArray *	fDevices

TObjArray *	fDevs
	! Temp. array to hold references to user selected devices

TObject *	fDisplay
	! Temp. pointer to hold objects which serve event displays

TObjArray *	fOrdered
	! Temp. array to hold references to various ordered objects

TObjArray *	fThits
	! Temp. array to hold references to the registered NcDevice hits

Protected Attributes inherited from NcDevice
Int_t	fHitCopy

TObjArray *	fHits

TObjArray *	fMarkers
	! Temp. array to hold the 3D markers for the hit display

TObjArray *	fOrdered
	! Temp. array to hold the ordered hits

Int_t	fStatus

Protected Attributes inherited from NcSignal
TObject *	fDevice

TArrayF *	fDsignals

NcObjMatrix *	fLinks

TObjArray *	fSamples

TArrayI *	fSigflags

TArrayF *	fSignals

TObjArray *	fTracks

TObjArray *	fWaveforms

Protected Attributes inherited from NcPosition
Float_t	fScale

NcTimestamp *	fTstamp

Protected Attributes inherited from Nc3Vector
Double32_t	fDresult
	! Error on scalar result (e.g. norm or dotproduct)

Int_t	fNv

Double32_t *	fV

Protected Attributes inherited from NcAttrib
TArrayI *	fCalflags

TObjArray *	fCalfuncs

TObjArray *	fDecalfuncs

TArrayF *	fGains

TObjArray *	fNames

TArrayF *	fOffsets

Constructor & Destructor Documentation

◆ NcDetector() [1/2]

NcDetector::NcDetector	(	const char *	name = "",
		const char *	title = "" )

// Default constructor.

Definition at line 200 of file NcDetector.cxx.

◆ ~NcDetector()

NcDetector::~NcDetector ( )

virtual

// Default destructor.

Definition at line 209 of file NcDetector.cxx.

◆ NcDetector() [2/2]

NcDetector::NcDetector ( const NcDetector & q )

// Copy constructor.

Definition at line 218 of file NcDetector.cxx.

Member Function Documentation

◆ Clone()

TObject * NcDetector::Clone ( const char * name = "" ) const

virtual

// Make a deep copy of the current object and provide the pointer to the copy.
// This memberfunction enables automatic creation of new objects of the
// correct type depending on the object type, a feature which may be very useful
// for containers like NcEvent when adding objects in case the
// container owns the objects.

Reimplemented from NcDetectorUnit.

Reimplemented in RnoDetector.

Definition at line 227 of file NcDetector.cxx.

The documentation for this class was generated from the following files:

ncfspack/source/NcDetector.h
ncfspack/source/NcDetector.cxx
